ONTROL P-I0N 44

P-ION series control panels are programmable devices used for controlling various systems, primarily heating, cooling, and ventilation (HVAC), in modern buildings.
Thanks to the Sedona Framework™ foundation, any kind of custom scenario required to meet building needs can be configured.

All universal inputs can be set as analog or voltage-free contact inputs.

Analog inputs are optimized for some passive resistive temperature sensing elements (such as PT1000) and 0-10VDC voltage signals. The 13-bit A/D converter ensures high-resolution and accurate measurement. A 500 Ohm resistor is required for (0)4-20 mA signals.

It is also possible to read the resistance value directly from the analog input. This allows the use of temperature sensing elements from different brands in the system.
All inputs are protected against short circuits and direct exposure to 50VAC.
