V Series Mass Flow Meter FCKD

V series Mass Flow Meters FCKD are precise measuring products that measure the mass, density, and temperature of the fluid simultaneously without being affected by the density in liquid or gas phase fluids. The measurement range is available from 0...1 to 0...500 kg/min. Standard 4-20 mA, Pulse, and Relay outputs are available. The wetted parts are standard as AISI316 and can also be produced as Hastelloy C. You can see the instantaneous flow and total flow values with the digital display on it. Our product, which has a Coriolis Mass Flowmeter Accuracy of 0.2%, can be powered by 24 VDC. The process connection is DN15...DN100, and the maximum operating pressure is 40 Bar. Ex-proof options are available for environments with explosion risk.
