SEN3251 Series Flush Diaphragm Pressure Sensor

SEN3251 Series Flush Diaphragm Pressure Sensor_1
Ask for Price
Türkiye / İstanbul / Beşiktaş
Ad No 1443015215
Ad Date 29 May 2025
Category Pressure gauge
Brand KOBOLD
Report This Ad

The SEN-3251 Series diaphragm pressure sensor is used for pressure and pressure-dependent level measurement of hard, viscous, or crystalline products thanks to its flush diaphragm. With its all stainless steel design, the product can be used in aggressive products and environments and is suitable for use in challenging working conditions.

Brand

KOBOLD

Model

SEN3251

Measuring cell material

Piezoresistive

Version

Flush diaphragm

Measuring range

-1…+25 barg (Select from brochure)

Process temperature

-30…+100 °C

Body material

Stainless steel 1.4301 / 304L

Process connection

G 1" / G ½" male thread

Output signal

4…20 mA (two-wire)

Power supply

10…30 VDC

Electrical connection

DIN 43650 A Valve socket

Protection class

IP65

Accuracy class

0.50 %  / 0.25% (optional)
