Immersion Type Thermal Mass Flow Meter CTMD

With the CTMD series Thermal Mass Flow Meters, you can easily install them even on large diameter pipes and obtain accurate measurements. It is sufficient to drill a hole on the pipe for connection and immerse the sensor part into it. Our product, which can measure with 1.5% accuracy in the read value, has a measuring capability of 100:1. Our device includes RS485 or HART communication protocol, and offers 4...20 mA and Pulse output options. The wet parts of our product are made of AISI316 SS stainless material, and its measuring range is 0...150 Nm/s. It has an instantaneous and total indicator on it. It can withstand pressure up to 40 Bar.
